UL Certified

Hygienic hand drying solution, 35-second lockout feature if hands are not removed

95% cost savings vs. paper towels

Electric Specifications: 208–277V 5.6 – 6.2A

Meets ADA requirements without the need of a recess kit

Adjustable speed and sound (High-Low), Adjustable Heat (High-Low-Off)

Vandal resistant cover design, Virtually maintenance free

Available in Polished White and Brushed Nickel

Weight: 8-10 lbs.

Quantity Recommendations: 1 dryer for every 2 sink stations is sufficient for most applications. For high traffic applications we suggest 1 dryer per sink station

Suggested Mounting Heights for Ideal Performance (from floor to bottom of dryer): Men: 45” (114 cm), Women: 43” (109 cm), Teenagers: 41” (104 cm), Children: 35” (89 cm), ADA: 37” (94 cm). Note: When mounting for any user ensure that it is mounted below the 48” ADA Maximum

Externally visible Red LED light that flashes error codes to assist in troubleshooting and identify if filter has been clogged

Air temperature of up to 141°F (61°C) at a 72°F (22°C) ambient room temperature at the hands (4 inches [102 mm] below air outlet)

Flush volumes start as low as 1.0 gpf/3.8 Lpf

Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents urinal from exceeding intended flush volume

Flush accuracy is controlled by CID™ technology, also enhancing water efficiency

Integrity of the product is maintained with the vandal-resistant stop cap

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance

Adjustable tailpiece to accommodate different height requirements

High chloramine resistant PERMEX® Synthetic Rubber Diaphragm with Linear Filtered Bypass and Vortex Cleansing Action

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Includes the required wall plate and a purple wall flange to let users know reclaimed water is in use

All organic rubber has been replaced with synthetic compounds

Optional purple handle provides additional indication of reclaimed water use

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Hygienic hand drying solution, 14 second dry time

Electric Specifications: 110-120V – 7-7.7 Amps, 770-915 Watts, 50/60 Hz, Can install multiple units on one circuit

Meets ADA requirements without the need of a recess kit

Adjustable speed and sound (High-Low), Adjustable Heat (High-Low-Off)

95% cost savings vs. paper towels

Weight: 8-10 lbs.

Vandal resistant cover design, Virtually maintenance free

Suggested Mounting Heights for Ideal Performance (from floor to bottom of dryer): Men: 45” (114 cm), Women: 43” (109 cm), Teenagers: 41” (104 cm), Children: 35” (89 cm), ADA: 37” (94 cm). Note: When mounting for any user ensure that it is mounted below the 48” ADA Maximum

Externally visible Red LED light that flashes error codes to assist in troubleshooting and identify if filter has been clogged

Air temperature of up to 141°F (61°C) at a 72°F (22°C) ambient room temperature at the hands (4 inches [102 mm] below air outlet).

35-second lockout feature if hands are not removed

35-second lockout feature if hands are not removed, 10 second dry time

95% cost savings vs. paper towels, Adjustable speed and sound (High-Low)

Electric Specifications: 110-120V – 4.3-4.5 Amps, 460-530 Watts, 50/60 Hz, Can install multiple units on one circuit

Externally visible Red LED light that flashes error codes to assist in troubleshooting and identify if filter has been clogged

Hygienic hand drying solution, No Heat option

Quantity Recommendations: 1 dryer for every 2 sink stations is sufficient for most applications. For high traffic applications we suggest 1 dryer per sink station.

Suggested Mounting Heights for Ideal Performance (from floor to bottom of dryer): Men: 45” (114 cm), Women: 43” (109 cm), Teenagers: 41” (104 cm), Children: 35” (89 cm), ADA: 37” (94 cm). Note: When mounting for any user ensure that it is mounted below the 48” ADA Maximum

Vandal resistant cover design, Virtually maintenance free

Weight: 15-17 lbs.

8 second dry time, Weight: 15-17 lbs.

95% cost savings vs. paper towels

Air temperature of up to 135°F (57°C) at a 72°F (22°C) ambient room temperature at the hands (4 inches [102 mm] below air outlet).

Automatically operates by means of an Infrared Optical Sensor with 35-second lockout feature, it activates a strong controlled air blast

Can be easily positioned to comply with ADA requirements or for juvenile height

Vandal resistant cover design, Virtually maintenance free

Electric Specifications: 110-120V – 11.3-12.2 Amps, 1240-1450 Watts, 50/60 Hz, can install multiple units on one circuit

Externally visible Red LED light that flashes error codes to assist in troubleshooting and identify if filter has been clogged

One-piece heavy-duty rib reinforced die cast zinc alloy housing minimizes damage to dryer in abusive environments

Quantity Recommendations: 1 dryer for every 2 sink stations is sufficient for most applications. For high traffic applications we suggest 1 dryer per sink station.

Suggested Mounting Heights for Ideal Performance (from floor to bottom of dryer): Men: 45” (114 cm), Women: 43” (109 cm), Teenagers: 41” (104 cm), Children: 35” (89 cm), ADA: 37” (94 cm). Note: When mounting for any user ensure that it is mounted below the 48” ADA Maximum

Adjustable Infrared Sensor Range

36” (914 mm) Long Sensor Cable

24” (610 mm) Long Flex Hose

Filtered Solenoid Valve with serviceable Strainer Filter

Includes Four (4) AA-size Batteries

Includes appropriate Mounting Hardware

1 Year limited warranty

Splash-proof Circuit Control Module

Adjustable Infrared Sensor Range

36” (914 mm) Long Sensor Cable

24” (610 mm) Long Flex Hose

Filtered Solenoid Valve with serviceable Strainer Filter

Includes Four (4) AA-size Batteries

Includes appropriate Mounting Hardware

1 Year limited warranty

Adjustable Infrared Sensor Range

36” (914 mm) Long Sensor Cable

24” (610 mm) Long Flex Hose

Filtered Solenoid Valve with serviceable Strainer Filter

Includes Four (4) AA-size Batteries

Includes appropriate Mounting Hardware

1 Year limited warranty
