By admin , 9 October 2025

ROYAL 186 RW

Product Code
ROYAL 186 RW
Product Type
Parent
Date Updated
1773705600
Product Category
Flushometer
Url Slug
royal-186-rw
Compliances and Certifications
ADA Compliant
BAA Compliant
BABAA Compliant
Made in the USA
Satisfies LEED Credits
EPA WaterSense Listed
Primary Description
Royal® Manual Specialty Flushometer
Series Description
Royal® Exposed Manual Specialty Urinal Reclaimed Water Flushometer
Product Line
Royal®
Flushometer Installation
Exposed
Flushometer Activation
Manual Specialty
Flushometer Valve
Diaphragm
Flushometer Fixture Type
Urinal
Flushometer Specialty
Reclaimed Water
Flushometer Product Line
Royal®
Brochures
Retrofits Brochure
Installation Instruction
Royal Reclaimed Water Flushometer Installation Instructions
Repair & Maintenance Guide
Royal Manual Diaphragm Flushometer Repair and Maintenance Guide
Control Stop Repair and Maintenance Guide
Flush Connections Flanges Repair and Maintenance Guide
Tail Piece Repair and Maintenance Guide
Transparency Reports
Diaphragm Flushometers HPD
BIM Model
ROYAL 186 RW BIM Model
Maintenance Schedule
Flushometer Parts Maintenance Schedule
Manual Flushometer Maintenance Schedule Brochure
Rough-In Parent
ROYAL 186 RW - Rough-In Parent
Features List
Includes the required wall plate and a purple wall flange to let users know reclaimed water is in use.
All organic rubber has been replaced with synthetic compounds
Interior components are purple to let maintenance personnel know the flushometer is designed for reclaimed water
Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass
Optional purple handle provides additional indication of reclaimed water use.
PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass
Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass
Valve shall be in compliance to the applicable sections of ASSE 1037
By admin , 9 October 2025

ROYAL 153

Product Code
ROYAL 153
Product Type
Parent
Date Updated
1772668800
Product Category
Flushometer
Url Slug
royal-153
Compliances and Certifications
BAA Compliant
Made in the USA
Satisfies LEED Credits
EPA WaterSense Listed
Primary Description
Royal® Manual Flushometer
Series Description
Royal® Concealed Manual Water Closet Flushometer
Product Line
Royal®
Flushometer Installation
Concealed
Flushometer Activation
Manual
Flushometer Valve
Diaphragm
Flushometer Fixture Type
Water Closet
Flushometer Product Line
Royal®
Brochures
Retrofits Brochure
Flushometers Brochure
Installation Instruction
Sloan Concealed Installation Instructions
Repair & Maintenance Guide
Control Stop Repair and Maintenance Guide
Flush Connections Flanges Repair and Maintenance Guide
Tail Piece Repair and Maintenance Guide
Concealed Flushometers Repair and Maintenance Guide
CAD Drawing
Royal 153 Elevation View CAD Drawing
Royal 153 Plan View CAD Drawing
Maintenance Schedule
Manual Flushometer Maintenance Schedule Brochure
Flushometer Parts Maintenance Schedule
Rough-In Parent
ROYAL 153 - Rough-In Parent
Features List
Flush volumes start as low as 1.28 gpf/4.8 Lpf
Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents toilet from exceeding intended flush volume
Flush accuracy is controlled by CID™ technology, also enhancing water efficiency
Integrity of the product is maintained with the vandal-resistant stop cap
Durability is facilitated with high copper, low zinc brass castings for dezincification resistance
Adjustable tailpiece
PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass
Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass
Valve shall be in compliance to the applicable sections of ASSE 1037
By admin , 8 October 2025

WES 111-1.6/1.1-CP-CN

Rough-In Dimension (L Dimension)
11.5"
Spud Coupling
1.5"
Supply Pipe
1"
Product Code
3720000T
Product Type
Variations
Date Updated
1779321600
Product Category
Flushometer
Url Slug
wes-111-1-6-1-1-cp-cn
Compliances and Certifications
ADA Compliant
BAA Compliant
Carbon Neutral
Carbon Offset
LBC Credit
Made in the USA
WELL Building Standard
Finish
Polished Chrome
Product Line
UPPERCUT®
Flushometer Fixture Connection
Top Spud
Flushometer Flush Volume gpf
1.60gpf
Flushometer Water Efficiency
High Efficiency
Parent
WES 111
Flushometer Product Line
UPPERCUT®
Spec Sheet Description
1.6/1.1 gpf, Polished Chrome Finish, Fixture Connection Top Spud, Dual Flush, Carbon Neutral
Recommended Specifications
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.
By admin , 8 October 2025

ROYAL 186-0.25-CP

Bypass
Dual-Filtered Bypass
Rough-In Dimension (L Dimension)
11.5"
Spud Coupling
0.75"
Supply Pipe
0.75"
Product Code
3912648
Product Type
Variations
Date Updated
1779321600
Product Category
Flushometer
Url Slug
royal-186-0-25-cp
Compliances and Certifications
ADA Compliant
BAA Compliant
BABAA Compliant
HPD
LBC Credit
Made in the USA
Satisfies LEED Credits
EPA WaterSense Listed
WELL Building Standard
Finish
Polished Chrome
Product Line
Royal®
Flushometer Fixture Connection
Top Spud
Flushometer Flush Volume gpf
0.25gpf
Numeric lpf Flushometer Flush Volume
0.90lpf
Flushometer Water Efficiency
High Efficiency
Parent
ROYAL 186
Flushometer Product Line
Royal®
Spec Sheet Description
0.25 gpf, Dual-Filtered Bypass, Polished Chrome Finish, Fixture Connection Top Spud, Single Flush
Recommended Specifications
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.
By admin , 8 October 2025

SLOAN 186-0.25-CP

Bypass
Dual-Filtered Bypass
Rough-In Dimension (L Dimension)
11.5"
Spud Coupling
0.75"
Supply Pipe
0.75"
Product Code
3782661
Product Type
Variations
Date Updated
1779321600
Product Category
Flushometer
Url Slug
sloan-186-0-25-cp
Compliances and Certifications
ADA Compliant
BAA Compliant
cUPC Certified
Made in the USA
Satisfies LEED Credits
EPA WaterSense Listed
Finish
Polished Chrome
Product Line
Sloan®
Flushometer Fixture Connection
Top Spud
Flushometer Flush Volume gpf
0.25gpf
Numeric lpf Flushometer Flush Volume
0.90lpf
Flushometer Water Efficiency
High Efficiency
Parent
SLOAN 186
Flushometer Product Line
Sloan®
Spec Sheet Description
0.25 gpf, Dual-Filtered Bypass, Polished Chrome Finish, Fixture Connection Top Spud, Single Flush
Recommended Specifications
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.
By admin , 8 October 2025

SLOAN 186-0.125-CP

Bypass
Dual-Filtered Bypass
Rough-In Dimension (L Dimension)
11.5"
Spud Coupling
0.75"
Supply Pipe
0.75"
Product Code
3782643
Product Type
Variations
Date Updated
1779321600
Product Category
Flushometer
Url Slug
sloan-186-0-125-cp
Compliances and Certifications
ADA Compliant
BAA Compliant
BABAA Compliant
cUPC Certified
HPD
Made in the USA
Satisfies LEED Credits
EPA WaterSense Listed
Finish
Polished Chrome
Product Line
Sloan®
Flushometer Fixture Connection
Top Spud
Flushometer Flush Volume gpf
0.13gpf
Numeric lpf Flushometer Flush Volume
0.50lpf
Flushometer Water Efficiency
High Efficiency
Parent
SLOAN 186
Flushometer Product Line
Sloan®
Spec Sheet Description
0.125 gpf, Dual-Filtered Bypass, Polished Chrome Finish, Fixture Connection Top Spud, Single Flush
Recommended Specifications
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.
By admin , 8 October 2025

SLOAN 186-0.125-CP-SG

Bypass
Dual-Filtered Bypass
Handle Type
Saniguard®
Rough-In Dimension (L Dimension)
11.5"
Spud Coupling
0.75"
Supply Pipe
0.75"
Product Code
3782644
Product Type
Variations
Date Updated
1779321600
Product Category
Flushometer
Url Slug
sloan-186-0-125-cp-sg
Compliances and Certifications
ADA Compliant
BAA Compliant
cUPC Certified
Made in the USA
Satisfies LEED Credits
EPA WaterSense Listed
Finish
Polished Chrome
Product Line
Sloan®
Flushometer Fixture Connection
Top Spud
Flushometer Flush Volume gpf
0.13gpf
Numeric lpf Flushometer Flush Volume
0.50lpf
Flushometer Water Efficiency
High Efficiency
Parent
SLOAN 186
Flushometer Product Line
Sloan®
Spec Sheet Description
0.125 gpf, Dual-Filtered Bypass, Polished Chrome Finish, Fixture Connection Top Spud, Single Flush, Saniguard® Handle
Recommended Specifications
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.
By admin , 8 October 2025

ROYAL 186 RW-0.25-CP

Rough-In Dimension (L Dimension)
11.5"
Spud Coupling
0.75"
Supply Pipe
0.75"
Product Code
3012671
Product Type
Variations
Date Updated
1779321600
Product Category
Flushometer
Url Slug
royal-186-rw-0-25-cp
Compliances and Certifications
ADA Compliant
BAA Compliant
BABAA Compliant
Made in the USA
Satisfies LEED Credits
EPA WaterSense Listed
Finish
Polished Chrome
Product Line
Royal®
Flushometer Fixture Connection
Top Spud
Flushometer Flush Volume gpf
0.25gpf
Numeric lpf Flushometer Flush Volume
0.90lpf
Flushometer Water Efficiency
High Efficiency
Parent
ROYAL 186 RW
Flushometer Product Line
Royal®
Spec Sheet Description
0.25 gpf, Polished Chrome Finish, Fixture Connection Top Spud, Single Flush
Recommended Specifications
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.
By admin , 8 October 2025

GEM-2 186-1.5-XL-CP

Adapter
XL Sweat Solder Adapter Kit
Rough-In Dimension (L Dimension)
11.5"
Spud Coupling
0.75"
Supply Pipe
0.75"
Product Code
3072604
Product Type
Variations
Date Updated
1779321600
Product Category
Flushometer
Url Slug
gem-2-186-1-5-xl-cp
Compliances and Certifications
ADA Compliant
BAA Compliant
cUPC Certified
Made in the USA
Finish
Polished Chrome
Product Line
GEM-2®
Flushometer Fixture Connection
Top Spud
Flushometer Flush Volume gpf
1.50gpf
Numeric lpf Flushometer Flush Volume
5.70lpf
Flushometer Water Efficiency
Water Saver
Parent
GEM-2 186
Flushometer Product Line
GEM-2®
Spec Sheet Description
1.5 gpf, XL Sweat Solder Adapter Kit, Polished Chrome Finish, Fixture Connection Top Spud, Single Flush
Recommended Specifications
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.
By admin , 8 October 2025

GEM-2 186-1.0-XL-CP

Adapter
XL Sweat Solder Adapter Kit
Rough-In Dimension (L Dimension)
11.5"
Spud Coupling
0.75"
Supply Pipe
0.75"
Product Code
3072606
Product Type
Variations
Date Updated
1779321600
Product Category
Flushometer
Url Slug
gem-2-186-1-0-xl-cp
Compliances and Certifications
ADA Compliant
BAA Compliant
cUPC Certified
Made in the USA
Finish
Polished Chrome
Product Line
GEM-2®
Flushometer Fixture Connection
Top Spud
Flushometer Flush Volume gpf
1.00gpf
Numeric lpf Flushometer Flush Volume
3.80lpf
Flushometer Water Efficiency
Low Consumption
Parent
GEM-2 186
Flushometer Product Line
GEM-2®
Spec Sheet Description
1.0 gpf, XL Sweat Solder Adapter Kit, Polished Chrome Finish, Fixture Connection Top Spud, Single Flush
Recommended Specifications
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.
Made in the USA
