Made in the USA

Flush volumes start as low as a pint of water

Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents urinal from exceeding intended flush volume

Flush accuracy is controlled by CID™ technology, also enhancing water efficiency

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance

Adjustable tailpiece

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Flush volumes start as low as 1.28 gpf/4.8 Lpf

Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents toilet from exceeding intended flush volume

Flush accuracy is controlled by CID™ technology, also enhancing water efficiency

Integrity of the product is maintained with the vandal-resistant stop cap

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance

Adjustable tailpiece

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Flush volumes start as low as 1.28 gpf/4.8 Lpf

Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents toilet from exceeding intended flush volume

Flush accuracy is controlled by CID™ technology, also enhancing water efficiency

Integrity of the product is maintained with the vandal-resistant stop cap

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance

Adjustable tailpiece to accommodate different height requirements

High chloramine resistant PERMEX® Synthetic Rubber Diaphragm with Linear Filtered Bypass and Vortex Cleansing Action

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Flush volumes to meet water-efficiency goals

Unique cover design isolates threads from water source, protecting threads from harsh water conditions

Fixed volume piston with filtered O-ring bypass

ADA-compliant, metal oscillating, non-hold open handle with triple seal handle packing keeps fixture from exceeding intended flush volume

Locking, vandal-resistant stop cap prevents tampering

Adjustable tailpiece accommodates different widths

High copper, low zinc brass casting for dezincification resistance ensures long life

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Lift handle to initiate reduced, 1.1 gpf flush to eliminate liquid and paper waste, saving one-half gallon of water

Push handle down for a regular 1.6 gpf flush to remove solid waste and paper

Antimicrobial coating on handle lasts for the life of the product

Green handle signifies UPPERCUT’s water-saving features

Comes with two metal wall plates that provide operational instructions

Includes all the reliable, long-lasting features of the Royal® Flushometer

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents toilet from exceeding intended flush volume

Flush accuracy is controlled by CID™ technology, also enhancing water efficiency

Integrity of the product is maintained with the vandal-resistant stop cap

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance

Adjustable tailpiece

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents urinal from exceeding intended flush volume

Flush accuracy is controlled by CID™ technology, also enhancing water efficiency

Integrity of the product is maintained with the vandal-resistant stop cap

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance

Adjustable tailpiece

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Flush volumes to meet water-efficiency goals

Unique cover design isolates threads from water source, protecting threads from harsh water conditions

Fixed volume piston with filtered O-ring bypass

ADA-compliant, metal oscillating, non-hold open handle with triple seal handle packing keeps fixture from exceeding intended flush volume

Locking, vandal-resistant stop cap prevents tampering

Adjustable tailpiece accommodates different widths

High copper, low zinc brass casting for dezincification resistance ensures long life

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Flush volume is factory set with option of adjusting volume range according to specific needs

Flushing control mechanism functions in oil and is isolated from debris

Water pressure not required to positively shut off

Complies with military specifications

Regulating screw for flush duration control

Adjustable tailpiece

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Includes the required wall plate and a purple wall flange to let users know reclaimed water is in use.

All organic rubber has been replaced with synthetic compounds

Interior components are purple to let maintenance personnel know the flushometer is designed for reclaimed water

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

Optional purple handle provides additional indication of reclaimed water use.

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037
