WELL Building Standard

Deploys an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

User-friendly, three-second flush delay

High copper, low zinc brass castings for dezincification resistance

Fixed metering bypass and no external volume adjustment to ensure water conservation

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Water-efficient flush volume of either .13 gpf or .25 gpf

Automatically operates by means of an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

User-friendly, three-second flush delay

High copper, low zinc brass castings for dezincification resistance

Fixed metering bypass and no external volume adjustment to ensure water conservation

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Includes the required wall plate and a purple wall flange to let users know reclaimed water is in use.

All organic rubber has been replaced with synthetic compounds

Interior components are purple to let maintenance personnel know the flushometer is designed for reclaimed water

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

Optional purple handle provides additional indication of reclaimed water use.

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Main Seat, Stop Seat and Vacuum Breaker Molded from PERMEX® Rubber Compound for Chloramine resistance

User-friendly, three-second flush delay

“Low Battery” Flashing LED

High Copper, low zinc brass castings for dezincification resistance

Solar Powered- The sensor assembly is powered by a solar cell that will harvest power from the artificial indoor light (incandescent, fluorescent or LED), and use it as the energy source. The solar cell can provide approximately 100% power with 650 illuminance (lux).

Four (4) Size AA Battery Back-up Power Source

Fixed metering bypass and no external volume adjustment to ensure water conservation

Infrared Sensor with Multiple-focused, Lobular Sensing Fields for high and low target detection

Valve shall be in compliance to the applicable sections of ASSE 1037

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

User friendly three (3) second Flush Delay

“Low Battery” Flashing LED

Solar Powered- The sensor assembly is powered by a solar cell that will harvest power from the artificial indoor light (incandescent, fluorescent or LED), and use it as the energy source. The solar cell can provide approximately 100% power with 650 illuminance (lux).

Operates by means of an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

Four (4) Size AA Battery Back-up Power Source

Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation

High copper, low zinc brass castings for dezincification resistance

Sweat solder adapter with cover tube and cast wall flange with set screw

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve shall be in compliance to the applicable sections of ASSE 1037

Valve body, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Complete urinal system including ECOS HW flushometer Designed to maximize performance

Thorough washdown flushing action

Durable, hygienic vitreous china construction

Vandal resistant stainless steel strainer included

IAPMO certified to meet or exceed ASME A112.19.2 standards

Water Sense listed by EPA that qualifies for most rebate programs

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly

Complete urinal system including Royal flushometer Designed to maximize performance

Thorough washdown flushing action

Durable, hygienic vitreous china construction

Vandal resistant stainless steel strainer included

IAPMO certified to meet or exceed ASME A112.19.2 standards

Water Sense listed by EPA that qualifies for most rebate programs

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly

Complete urinal system including ECOS flushometer Designed to maximize performance

Thorough washdown flushing action

Durable, hygienic vitreous china construction

Vandal resistant stainless steel strainer included

IAPMO certified to meet or exceed ASME A112.19.2 standards

Water Sense listed by EPA that qualifies for most rebate programs

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly

Complete urinal system including Solis flushometer Designed to maximize performance

Thorough washdown flushing action

Durable, hygienic vitreous china construction

Vandal resistant stainless steel strainer included

IAPMO certified to meet or exceed ASME A112.19.2 standards

Water Sense listed by EPA that qualifies for most rebate programs

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly

Complete urinal system including Royal flushometer Designed to maximize performance

Thorough washdown flushing action

Durable, hygienic vitreous china construction

Vandal resistant stainless steel strainer included

IAPMO certified to meet or exceed ASME A112.19.2 standards

Water Sense listed by EPA that qualifies for most rebate programs

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly
