Water-efficient flush volume of either .13 gpf or .25 gpf

Automatically operates by means of an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

User-friendly, three-second flush delay

High copper, low zinc brass castings for dezincification resistance

Fixed metering bypass and no external volume adjustment to ensure water conservation

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Includes the required wall plate and a purple wall flange to let users know reclaimed water is in use.

All organic rubber has been replaced with synthetic compounds

Interior components are purple to let maintenance personnel know the flushometer is designed for reclaimed water

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

Optional purple handle provides additional indication of reclaimed water use.

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Includes the required wall plate and a purple wall flange to let users know reclaimed water is in use.

All organic rubber has been replaced with synthetic compounds

Interior components are purple to let maintenance personnel know the flushometer is designed for reclaimed water

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

Optional purple handle provides additional indication of reclaimed water use.

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Handle Packing, Main Seat, Stop Seat and Vacuum Breaker Molded from PERMEX® Rubber Compound for Chloramine resistance

User-friendly, three-second flush delay and Courtesy Flush® override button

“Low Battery” Flashing LED

Sweat solder adapter with cover tube and cast wall flange with set screw

Solar Powered- The sensor assembly is powered by a solar cell that will harvest power from the artificial indoor light (incandescent, fluorescent or LED), and use it as the energy source. The solar cell can provide approximately 100% power with 650 illuminance (lux).

Four (4) Size AA Battery Back-up Power Source

Synthetic rubber seals for chloramine resistance

Infrared Sensor with Multiple-focused, Lobular Sensing Fields for high and low target detection

Fixed metering bypass and no external volume adjustment to ensure water conservation

Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation

Engineered Metal Cover with replaceable Lens Window

ADA Compliant Sloan Solis® Solar Powered Infrared Sensor for automatic “No Hands” operation

3/4” IPS screwdriver Bak-Chek® angle stop with vandal resistant stop cap

User-friendly, three-second flush delay and Courtesy Flush® override button

High Copper, low zinc brass castings for dezincification resistance

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Handle Packing, Main Seat, Stop Seat and Vacuum Breaker Molded from PERMEX® Rubber Compound for Chloramine resistance

User friendly three (3) second Flush Delay

“Low Battery” Flashing LED

Sweat solder adapter with cover tube and cast wall flange with set screw

State-of-the-art photovoltaic technology delivers solar operation

Solar Powered- The sensor assembly is powered by a solar cell that will harvest power from the artificial indoor light (incandescent, fluorescent or LED), and use it as the energy source. The solar cell can provide approximately 100% power with 650 illuminance (lux).

Four (4) Size AA Battery Back-up Power Source

Operates by means of an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation

Flex Tube Diaphragm designed for improved life and reduced maintenance

Engineered Metal Cover with replaceable Lens Window

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Courtesy Flush® Override Button

Override button enables manual flushing if sensor’s power source fails

High copper, low zinc brass castings for dezincification resistance

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Wireless connected device for real time diagnostic and adjustable product settings

Sloan Connect App® readily available for smart phone and tablet devices

User friendly three (3) second Flush Delay

“Low Battery” Flashing LED

Sweat solder adapter with cover tube and cast wall flange with set screw

State-of-the-art photovoltaic technology delivers solar operation

Solar Powered- The sensor assembly is powered by a solar cell that will harvest power from the artificial indoor light (incandescent, fluorescent or LED), and use it as the energy source. The solar cell can provide approximately 100% power with 650 illuminance (lux).

Four (4) Size AA Battery Back-up Power Source

Operates by means of an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation

Flex Tube Diaphragm designed for improved life and reduced maintenance

Engineered Metal Cover with replaceable Lens Window

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Courtesy Flush® Override Button

High copper, low zinc brass castings for dezincification resistance

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Exposed water closet, diaphragm model Flushometer is intended for floor-mounted or wall-hung top spud bowls

Incorporates a patented one-piece construction body design, maintaining the spray arm in an upright position

Presents a leaner, more aesthetic installation, reducing possible bacteria growth on hidden and hard-to-reach surfaces found on other bedpan washer units

Eliminates the need for unsanitary hose sprays, as well as the additional housekeeping that hoses require and the potential for patient slippage

Valve body, stop body, diverter body and diverter pivot made from brass casting using semi-red brass for durability and long life

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Exposed water closet, diaphragm model Flushometer is intended for floor-mounted or wall-hung top spud bowls

Operates by means of a metal oscillating, non-hold-open handle with a triple seal handle packing to ensure water conservation

Presents a leaner, more aesthetic installation, reducing possible bacteria growth on hidden and hard-to-reach surfaces found on other bedpan washer units

Eliminates the need for unsanitary hose sprays, as well as the additional housekeeping that hoses require and the potential for patient slippage

Valve body, stop body, diverter body and diverter pivot made from brass casting using semi-red brass for durability and long life

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Exposed water closet, diaphragm model Flushometer is intended for floor-mounted or wall-hung top spud bowls

Operates by means of a metal oscillating, non-hold-open handle with a triple seal handle packing to ensure water conservation

Presents a leaner, more aesthetic installation, reducing possible bacteria growth on hidden and hard-to-reach surfaces found on other bedpan washer units

Eliminates the need for unsanitary hose sprays, as well as the additional housekeeping that hoses require and the potential for patient slippage

Valve body, stop body, diverter body and diverter pivot made from brass casting using semi-red brass for durability and long life

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Non-hold-open oscillating handle, Bak-Chek™ control stop and self-cleaning Xpelor Metering By-Pass ensure reliable operation and accurate flush delivery

Available with adjustable or ground joint supply stop (ground joint recommended for salt water applications)

Factory set flush volume of either 1.6 gpf/6.0 Lpf or 3.5 gpf/13.2 Lpf with adjustment range of 1.5 gpf/5.7 Lpf to 7.0 gpf/26.5 Lpf

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Sweat solder kit not provided, order separately if required.
