Parent

Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents toilet from exceeding intended flush volume

Flush accuracy is controlled by CID™ technology, also enhancing water efficiency

Integrity of the product is maintained with the vandal-resistant stop cap

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance

Adjustable tailpiece

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Automatically initiates a 1.1 gpf or 1.6 gpf flush based on how long the user remains in sensor range

Buttons on top of the flush valve enable manual flushing with a full or reduced flush at restroom visitor’s discretion

Employs an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

User-friendly, three-second flush delay

High copper, low zinc brass castings for dezincification resistance

Fixed metering bypass and no external volume adjustment to ensure water conservation

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Flush volumes start as low as 1.28 gpf/4.8 Lpf

Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents toilet from exceeding intended flush volume

Flush accuracy is controlled by CID™ technology, also enhancing water efficiency

Integrity of the product is maintained with the vandal-resistant stop cap

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance

Adjustable tailpiece

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

All organic rubber has been replaced with synthetic compounds

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

All organic rubber has been replaced with synthetic compounds

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

All organic rubber has been replaced with synthetic compounds

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

All organic rubber has been replaced with synthetic compounds

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

True flushometer provides accurate flush volume

Heavy-duty rough brass valve body

Battery powered infrared sensor provides hands free activation

Vandal-resistant wall plate with electronic override button

Replaceable piston assembly accessible though front wall plate

Concealed shut off sleeve adjusts flow rate

Not available in USA or Canada

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Wireless connected device for real time diagnostic and adjustable product settings

Sloan Connect App® readily available for smart phone and tablet devices

User friendly three (3) second Flush Delay

“Low Battery” Flashing LED

Sweat solder adapter with cover tube and cast wall flange with set screw

Four (4) Size AA Battery Power Source

Operates by means of an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation

Flex Tube Diaphragm designed for improved life and reduced maintenance

Engineered Metal Cover with replaceable Lens Window

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Courtesy Flush® Override Button

High copper, low zinc brass castings for dezincification resistance

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Dual-flush model automatically initiates a reduced or complete flush based on how long user remains in sensor range, buttons on top of the flush valve enable manual flushing with a standard or reduced flush at restroom visitor’s discretion

Deploys an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

User-friendly, three-second flush delay

High copper, low zinc brass castings for dezincification resistance

Fixed metering bypass and no external volume adjustment to ensure water conservation

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037
