This soap is a uncolored and unscented foam soap. It comes in a 1,500 ml bottle that includes a new black straw that is inserted into the soap dispenser.

This soap is used on the ESD-410, ESD-420, ESD-500, ESD-600, ESD-700, ESD-800, ESD-1500, ESD-2000 and ESD-2100 Sloan Soap Dispensers.

This soap is also used in the combo units associated with each of those dispensers

Each soap dispenser ships with 2 bottles of this 1500 ml soap

Each use is 1 ml, in turn an estimated 1,500 uses per bottle before refill is needed

Additional foam soap can be purchased through Sloan (ESD-325) or GOJO distribution (8565-04-N6300GN)

These bottles cannot be refilled after use. They must be recycled and a new bottle inserted into the dispenser. If they are refilled with a different soap it will void the warranty on the soap dispenser.

Hygienic hand drying solution, 35-second lockout feature if hands are not removed

95% cost savings vs. paper towels

Electric Specifications: 208–277V 5.6 – 6.2A

Meets ADA requirements without the need of a recess kit

Adjustable speed and sound (High-Low), Adjustable Heat (High-Low-Off)

Vandal resistant cover design, Virtually maintenance free

Available in Polished White and Brushed Nickel

Weight: 8-10 lbs.

Quantity Recommendations: 1 dryer for every 2 sink stations is sufficient for most applications. For high traffic applications we suggest 1 dryer per sink station

Suggested Mounting Heights for Ideal Performance (from floor to bottom of dryer): Men: 45” (114 cm), Women: 43” (109 cm), Teenagers: 41” (104 cm), Children: 35” (89 cm), ADA: 37” (94 cm). Note: When mounting for any user ensure that it is mounted below the 48” ADA Maximum

Externally visible Red LED light that flashes error codes to assist in troubleshooting and identify if filter has been clogged

Air temperature of up to 141°F (61°C) at a 72°F (22°C) ambient room temperature at the hands (4 inches [102 mm] below air outlet)

Flush volumes start as low as 0.125 gpf/0.5 Lpf

Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents urinal from exceeding intended flush volume

Flush accuracy is controlled by CID™ technology, also enhancing water efficiency

Integrity of the product is maintained with the vandal-resistant stop cap

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance

Adjustable tailpiece to accommodate different height requirements

High chloramine resistant PERMEX® Synthetic Rubber Diaphragm with Linear Filtered Bypass and Vortex Cleansing Action

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

High chloramine resistant PERMEX®synthetic rubber diaphragm with Linear Filtered Bypass and Vortex Cleansing Action

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Flush volumes start at 0.125 gpf/0.5 Lpf

Fixed volume piston with filtered O-ring bypass and ADA-compliant, metal oscillating non-hold-open handle ensure reliable, water-efficient operation

Integrity of the product is maintained with control stop plug

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance and components made from PERMEX® rubber compound for chloramine resistance

Adjustable tailpiece

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Fixed volume piston with filtered O-ring bypass

Front access wall plate requires no rear access plumbing chase

ADA compliant push button

Vandal resistant wall plate

Adjustable flush connection

8 1⁄2”(W) x 9 1⁄4”(H) Wall Box Panel Dimension
