Naval

Image Product Line
Naval
By admin , 9 October 2025

NAVAL 111

Product Code
NAVAL 111
Product Type
Parent
Date Updated
1776124800
Product Category
Flushometer
Url Slug
naval-111
Compliances and Certifications
ADA Compliant
BAA Compliant
Primary Description
Naval Manual Flushometer
Series Description
Naval Exposed Manual Water Closet Flushometer
Product Line
Naval
Flushometer Installation
Exposed
Flushometer Activation
Manual
Flushometer Valve
Piston
Flushometer Fixture Type
Water Closet
Flushometer Product Line
Naval
Brochures
Flushometers Brochure
Installation Instruction
Naval Piston Type Exposed Installation Instructions
Repair & Maintenance Guide
Control Stop Repair and Maintenance Guide
Flush Connections Flanges Repair and Maintenance Guide
Tail Piece Repair and Maintenance Guide
Naval Repair and Maintenance Guide
BIM Model
NAVAL 111 BIM Model
CAD Drawing
Naval 111 Plan View CAD Drawing
Naval 111 Elevation View CAD Drawing
Maintenance Schedule
Manual Flushometer Maintenance Schedule Brochure
Flushometer Parts Maintenance Schedule
Rough-In Parent
NAVAL 111 - Rough-In Parent
Features List
Non-hold-open oscillating handle, Bak-Chek™ control stop and self-cleaning Xpelor Metering By-Pass ensure reliable operation and accurate flush delivery
Available with adjustable or ground joint supply stop (ground joint recommended for salt water applications)
Factory set flush volume of either 1.6 gpf/6.0 Lpf or 3.5 gpf/13.2 Lpf with adjustment range of 1.5 gpf/5.7 Lpf to 7.0 gpf/26.5 Lpf
Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Red Brass
Valve shall be in compliance to the applicable sections of ASSE 1037
Sweat solder kit not provided, order separately if required.
By admin , 8 October 2025

NAVAL 111-1.6-CP

Rough-In Dimension (L Dimension)
11.5"
Spud Coupling
1.5"
Supply Pipe
1"
Product Code
3140011
Product Type
Variations
Date Updated
1779321600
Product Category
Flushometer
Url Slug
naval-111-1-6-cp
Compliances and Certifications
ADA Compliant
BAA Compliant
Finish
Polished Chrome
Product Line
Naval
Flushometer Fixture Connection
Top Spud
Flushometer Flush Volume gpf
1.60gpf
Numeric lpf Flushometer Flush Volume
6.00lpf
Flushometer Water Efficiency
Low Consumption
Parent
NAVAL 111
Flushometer Product Line
Naval
Spec Sheet Description
1.6 gpf, Polished Chrome Finish, Fixture Connection Top Spud, Single Flush
Recommended Specifications
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.
Naval
