Product Code
ECOS 8186 BT
Product Type
Date Updated
1761264000
Product Category
Url Slug
ecos-8186-bt
Primary Description
ECOS® Sensor Flushometer
Product Features
Features List
Wireless connected device for real time diagnostic and adjustable product settings
Sloan Connect App® readily available for smart phone and tablet devices
“Low Battery” Flashing LED
Sweat solder adapter with cover tube and cast wall flange with set screw
Four (4) Size AA Battery Power Source
Operates by means of an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection
Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation
Flex Tube Diaphragm designed for improved life and reduced maintenance
Engineered Metal Cover with replaceable Lens Window
PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass
Courtesy Flush® Override Button
High copper, low zinc brass castings for dezincification resistance
Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass
Valve shall be in compliance to the applicable sections of ASSE 1037
Downloads
Downloads Product Group
Title
BIM Model
Files Dowloads
Title
Brochure
Files Dowloads
Title
Installation Instructions
Title
Repair & Maintenance Guide
Title
Transparency Reports
Files Dowloads
General Spec Sheet
Series Description
ECOS® Exposed Sensor Urinal Flushometer
Informational Videos
Product Line
Flushometer Installation
Exposed
Flushometer Activation
Sensor
Flushometer Valve
Diaphragm
Flushometer Fixture Type
Urinal
Smart Flushometer
Bluetooth
Flushometer Product Line
