One tool service

All wetted components to be stainless steel, engineered thermoplastic, EPDM, and copper or copper alloy

Solenoid housed in removable carrier that includes supply strainer

Integral water supply shut off

Supply strainer serviceable from above deck

Vandal resistant spray insert, key housed inside faucet body

All electronics sealed to IP-67

Gold plated electrical contacts

Above deck individual diagnostic indicators for battery life, solenoid condition, and power-up mode

Flexible, high pressure supply hoses, 3/8” compression connections

Bi-stable magnetic solenoid

Four (4) “AA” alkaline batteries

Double infrared sensors with automatic setting feature

Single hole installation

Includes all mounting hardware

Line purge mode, eliminates stagnant water

Adjustable time-outs

3 year limited warranty

Fixed volume piston with filtered O-ring bypass

Front access wall plate requires no rear access plumbing chase

Sensor activated, hands-free operation

Battery operated with hardwired option

Electronic override button

Low battery indicator light

Vandal resistant wall plate

Adjustable flush connection

8 1⁄2”(W) x 9 1⁄4”(H) Wall Box Panel Dimension

Designed to maximize and complement Sloan flushometers

Small size and clean lines fits a large variety of applications and restroom looks

Thorough washdown flushing action

Vandal resistant stainless steel strainer included

IAPMO certified to meet or exceed ASME A112.19.2 standards

Water Sense listed by EPA that qualifies for most rebate programs

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly

Fixed volume piston with filtered O-ring bypass

Front access wall plate requires no rear access plumbing chase

Sensor activated, hands-free operation

Battery operated with hardwired option

Electronic override button

low Battery indicator light

vandal resistant wall plate

Adjustable flush connection

Fixed volume piston with filtered O-ring bypass

Front access wall plate requires no rear access plumbing chase

ADA compliant push button

Vandal resistant wall plate

Adjustable flush connection

8 1⁄2”(W) x 9 1⁄4”(H) Wall Box Panel Dimension

Designed to maximize and complement Sloan flushometers

Universal model works with Sloan flushometers from 1.1 to 1.6 gpf

Durable, hygienic vitreous china construction with elongated rim

Syphonjet flushing achieves 1000g Map Scores when used with Sloan flushometers

IAPMO certified to meet or exceed ASME A112.19.2 standards

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly

Designed to maximize and complement Sloan flushometers

Universal high-efficiency model works with 0.125, 0.25 and 0.5 gpf Sloan flushometers

Thorough washdown flushing action

Durable, hygienic vitreous china construction

Vandal resistant stainless steel strainer included

IAPMO certified to meet or exceed ASME A112.19.2 standards

Water Sense listed by EPA that qualifies for most rebate programs

Fixed volume piston with filtered O-ring bypass

Front access wall plate requires no rear access plumbing chase

Sensor activated, hands-free operation

Battery operated with hardwired option

Electronic override button

Low battery indicator light

Vandal resistant wall plate

Adjustable flush connection

8 1⁄2”(W) x 9 1⁄4”(H) Wall Box Panel Dimension

Designed to maximize and complement Sloan flushometers

Universal model works with Sloan flushometers from 1.1 to 1.6 gpf

Durable, hygienic vitreous china construction with elongated rim

Syphonjet flushing achieves 1000g Map Scores when used with Sloan flushometers

IAPMO certified to meet or exceed ASME A112.19.2 standards

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly

Fixed volume piston with filtered O-ring bypass

Front access wall plate requires no rear access plumbing chase

ADA compliant push button

Vandal resistant wall plate

Adjustable flush connection

8 1⁄2”(W) x 9 1⁄4”(H) Wall Box Panel Dimension

Fixed volume piston with filtered O-ring bypass

Front access wall plate requires no rear access plumbing chase

ADA compliant push button

Vandal resistant wall plate

Adjustable flush connection

8 1⁄2”(W) x 9 1⁄4”(H) Wall Box Panel Dimension

Designed to maximize and complement Sloan flushometers

Universal model works with Sloan flushometers from 1.1 to 1.6 gpf

Durable, hygienic vitreous china construction with elongated rim

Syphonjet flushing achieves 1000g Map Scores when used with Sloan flushometers

IAPMO certified to meet or exceed ASME A112.19.2 standards

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly

Designed to maximize and complement Sloan flushometers

Universal high-efficiency model works with 0.125, 0.25 and 0.5 gpf Sloan flushometers

Thorough washdown flushing action

Durable, hygienic vitreous china construction

Vandal resistant stainless steel strainer included

IAPMO certified to meet or exceed ASME A112.19.2 standards

Water Sense listed by EPA that qualifies for most rebate programs

Built in air dam technology that eliminates backsplash and updrafts

A monolithic console available in Corian or quartz

Basins can be sized to project requirements

Many customization options - see architectural worksheet for all options

Comes with deck mounted BASYS style hand dryers standard

Pairs great with Sloan faucets and soap dispensers

Adjustable Infrared Sensor Range

36” (914 mm) Long Sensor Cable

24” (610 mm) Long Flex Hose

Filtered Solenoid Valve with serviceable Strainer Filter

Includes Four (4) AA-size Batteries

Includes appropriate Mounting Hardware

1 Year limited warranty

Automatically operates by means of an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

User-friendly, three-second flush delay and Courtesy Flush® override button

Adjustable tailpiece

High copper, low zinc brass castings for dezincification resistance

Available in low consumption (1.6 gpf/6.0 Lpf), water saver (3.5 gpf/13.2 Lpf), and high efficiency (1.28 gpf/4.8 Lpf) models

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Designed to maximize and complement Sloan flushometers

Universal model works with Sloan flushometers from 1.1 to 1.6 gpf

Durable, hygienic vitreous china construction with elongated rim

Syphonjet flushing achieves 1000g Map Scores when used with Sloan flushometers

IAPMO certified to meet or exceed ASME A112.19.2 standards

WaterSense compliant when used with a WaterSense compliant flushometer

Automatically operates by means of an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

User-friendly, three-second flush delay and Courtesy Flush® override button

Adjustable tailpiece

High copper, low zinc brass castings for dezincification resistance

Available in low consumption (1.6 gpf/6.0 Lpf), water saver (3.5 gpf/13.2 Lpf), and high efficiency (1.28 gpf/4.8 Lpf) models

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

ADA-compliant flushometer automatically operates by means of a infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

Fixed metering bypass and no external volume adjustment to ensure water conservation

Adjustable tailpiece to accommodate different height requirements

High copper, low zinc brass castings for dezincification resistance

Available in 0.5 gpf/1.9 Lpf, low consumption (1.0 gpf/3.8 Lpf), water saver (1.5 gpf/5.7 Lpf), and conventional (3.5 gpf/13.2 Lpf) models

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Designed to maximize and complement Sloan flushometers

Small size and fully enclosed trapway provide attractive design

Thorough washdown flushing action

Vandal resistant stainless steel strainer included

IAPMO certified to meet or exceed ASME A112.19.2 standards

Water Sense listed by EPA that qualifies for most rebate programs

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly

Designed to maximize and complement Sloan flushometers

Universal model works with Sloan flushometers from 1.1 to 1.6 gpf

Durable, hygienic vitreous china construction with elongated rim

Syphonjet flushing achieves 1000g Map Scores when used with Sloan flushometers

IAPMO certified to meet or exceed ASME A112.19.2 standards

WaterSense compliant when used with a WaterSense compliant flushometer

Touch-free operation improves hand washing hygiene

Modular one-piece construction easily attaches to deck surface

All electronics in spout are sealed

Designed for drip free foam dispensing operation

Motor assembly will be suspended the under sink deck and connected to the soap dispenser spout

Motor assembly rotates 360 degrees for easy installation

Battery life of 45,000 activations. 1-2 years based on usage.

Approx. 1,500 dispenses per foam soap bottle

Ships with 2 bottles of ESD-325 non-scented, non-colored foam soap (1500ml per bottle)

Ships with battery pack (4 "D" Alkaline batteries included)

Double Infrared Sensors with Automatic Setup and Indicator Light

Automatic Self-adapting Sensor Technology

Low Battery Indicator

Magnetic Solenoid Valve

Water Supply Connection with Flexible High-pressure Hose and Strainer

6 Volt Lithium 2CR5 Commercial Battery included

Appropriate Mounting Hardware included

Optional 24 Hour Sentinel Activation

3 year limited warranty

Faucet: Double Infrared Sensors with Automatic Setting

Faucet: Automatic Self-adapting Sensor Technology

Faucet: Low Battery Indicator

Faucet: Magnetic Solenoid Valve

Faucet: Water Supply Connection with Flexible High-pressure Hose and Strainer

Faucet: 6 Volt Lithium 2CR5 Commercial Battery included

Faucet: Appropriate Mounting Hardware included

Faucet: Optional 24 Hour Sentinel Activation

Faucet: 3 year limited warranty

Soap Dispenser: Touch-free operation improves hand washing hygiene

Soap Dispenser: Modular one-piece construction easily attaches to deck surface

Soap Dispenser: All electronics in spout are sealed

Soap Dispenser: Designed for drip free foam dispensing operation

Soap Dispenser: Motor assembly will be suspended the under sink deck and connected to the soap dispenser spout

Soap Dispenser: Motor assembly rotates 360 degrees for easy installation

Soap Dispenser: Battery life of 45,000 activations. 1-2 years based on usage.

Soap Dispenser: Approx. 1,500 dispenses per foam soap bottle

Soap Dispenser: Ships with 2 bottles of ESD-325 non-scented, non-colored foam soap (1500ml per bottle)

Soap Dispenser: Can be ordered as individual soap dispenser (ESD-1500)

Soap Dispenser: Hardwired or battery powered

Touch-free operation improves hand washing hygiene

Modular one-piece construction easily attaches to deck surface

All electronics in spout are sealed

Designed for drip free foam dispensing operation

Motor assembly will be suspended the under sink deck and connected to the soap dispenser spout

Motor assembly rotates 360 degrees for easy installation

Battery life of 45,000 activations. 1-2 years based on usage.

Approx. 1,500 dispenses per foam soap bottle

Ships with 2 bottles of ESD-325 non-scented, non-colored foam soap (1500ml per bottle)

Ships with battery pack (4 "D" Alkaline batteries included)

Faucet: Double Infrared Sensors with Automatic Setting

Faucet: Automatic Self-adapting Sensor Technology

Faucet: Low Battery Indicator

Faucet: Magnetic Solenoid Valve

Faucet: Water Supply Connection with Flexible High-pressure Hose and Strainer

Faucet: 6 Volt Lithium 2CR5 Commercial Battery included

Faucet: Appropriate Mounting Hardware included

Faucet: Optional 24 Hour Sentinel Activation

Faucet: 3 year limited warranty

Soap Dispenser: Touch-free operation improves hand washing hygiene

Soap Dispenser: Modular one-piece construction easily attaches to deck surface

Soap Dispenser: All electronics in spout are sealed

Soap Dispenser: Designed for drip free foam dispensing operation

Soap Dispenser: Motor assembly will be suspended the under sink deck and connected to the soap dispenser spout

Soap Dispenser: Motor assembly rotates 360 degrees for easy installation

Soap Dispenser: Battery life of 45,000 activations. 1-2 years based on usage.

Soap Dispenser: Approx. 1,500 dispenses per foam soap bottle

Soap Dispenser: Ships with 2 bottles of ESD-325 non-scented, non-colored foam soap (1500ml per bottle)

Soap Dispenser: Can be ordered as individual soap dispenser (ESD-1500)

Soap Dispenser: Hardwired or battery powered

Double Infrared Sensors with Automatic Setup and Indicator Light

Automatic Self-adapting Sensor Technology

Low Battery Indicator

Magnetic Solenoid Valve

Water Supply Connection with Flexible High-pressure Hose and Strainer

6 Volt Lithium 2CR5 Commercial Battery included

Appropriate Mounting Hardware included

Optional 24 Hour Sentinel Activation

3 year limited warranty

8 second dry time

95% cost savings vs. paper towels

Air temperature of up to 135°F (57°C) at a 72°F (22°C) ambient room temperature at the hands (4 inches [102 mm] below air outlet).

Automatically operates by means of an Infrared Optical Sensor with 35-second lockout feature, it activates a strong controlled air blast

Can be easily positioned to comply with ADA requirements or for juvenile height

Can install multiple units on one circuit

Electric Specifications: 110-120V – 11.3-12.2 Amps, 1240-1450 Watts, 50/60 Hz

Externally visible Red LED light that flashes error codes to assist in troubleshooting and identify if filter has been clogged

One-piece heavy-duty rib reinforced die cast zinc alloy housing minimizes damage to dryer in abusive environments

Quantity Recommendations: 1 dryer for every 2 sink stations is sufficient for most applications. For high traffic applications we suggest 1 dryer per sink station.

Residual moisture is evaporated with a warm stream of air up to 135°F/57°C

Suggested Mounting Heights for Ideal Performance (from floor to bottom of dryer): Men: 45” (114 cm), Women: 43” (109 cm), Teenagers: 41” (104 cm), Children: 35” (89 cm), ADA: 37” (94 cm). Note: When mounting for any user ensure that it is mounted below the 48” ADA Maximum

Vandal resistant cover design

Virtually maintenance free

Weight: 15-17 lbs.
