Wireless connected device for real time diagnostic and adjustable product settings

Sloan Connect App® readily available for smart phone and tablet devices

User friendly three (3) second Flush Delay

“Low Battery” Flashing LED

Sweat solder adapter with cover tube and cast wall flange with set screw

State-of-the-art photovoltaic technology delivers solar operation

Solar Powered- The sensor assembly is powered by a solar cell that will harvest power from the artificial indoor light (incandescent, fluorescent or LED), and use it as the energy source. The solar cell can provide approximately 100% power with 650 illuminance (lux).

Four (4) Size AA Battery Back-up Power Source

Operates by means of an infrared sensor with multiple-focused, lobular sensing fields for high and low target detection

Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation

Flex Tube Diaphragm designed for improved life and reduced maintenance

Engineered Metal Cover with replaceable Lens Window

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Courtesy Flush® Override Button

High copper, low zinc brass castings for dezincification resistance

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Exposed water closet, diaphragm model Flushometer is intended for floor-mounted or wall-hung top spud bowls

Incorporates a patented one-piece construction body design, maintaining the spray arm in an upright position

Presents a leaner, more aesthetic installation, reducing possible bacteria growth on hidden and hard-to-reach surfaces found on other bedpan washer units

Eliminates the need for unsanitary hose sprays, as well as the additional housekeeping that hoses require and the potential for patient slippage

Valve body, stop body, diverter body and diverter pivot made from brass casting using semi-red brass for durability and long life

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Exposed water closet, diaphragm model Flushometer is intended for floor-mounted or wall-hung top spud bowls

Operates by means of a metal oscillating, non-hold-open handle with a triple seal handle packing to ensure water conservation

Presents a leaner, more aesthetic installation, reducing possible bacteria growth on hidden and hard-to-reach surfaces found on other bedpan washer units

Eliminates the need for unsanitary hose sprays, as well as the additional housekeeping that hoses require and the potential for patient slippage

Valve body, stop body, diverter body and diverter pivot made from brass casting using semi-red brass for durability and long life

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Exposed water closet, diaphragm model Flushometer is intended for floor-mounted or wall-hung top spud bowls

Operates by means of a metal oscillating, non-hold-open handle with a triple seal handle packing to ensure water conservation

Presents a leaner, more aesthetic installation, reducing possible bacteria growth on hidden and hard-to-reach surfaces found on other bedpan washer units

Eliminates the need for unsanitary hose sprays, as well as the additional housekeeping that hoses require and the potential for patient slippage

Valve body, stop body, diverter body and diverter pivot made from brass casting using semi-red brass for durability and long life

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Non-hold-open oscillating handle, Bak-Chek™ control stop and self-cleaning Xpelor Metering By-Pass ensure reliable operation and accurate flush delivery

Available with adjustable or ground joint supply stop (ground joint recommended for salt water applications)

Factory set flush volume of either 1.6 gpf/6.0 Lpf or 3.5 gpf/13.2 Lpf with adjustment range of 1.5 gpf/5.7 Lpf to 7.0 gpf/26.5 Lpf

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Sweat solder kit not provided, order separately if required.

Flush volume is factory set with option of adjusting volume range according to specific needs

Flushing control mechanism functions in oil and is isolated from debris

Water pressure not required to positively shut off

Complies with military specifications

Regulating screw for flush duration control

Adjustable tailpiece

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Includes the required wall plate and a purple wall flange to let users know reclaimed water is in use.

All organic rubber has been replaced with synthetic compounds

Interior components are purple to let maintenance personnel know the flushometer is designed for reclaimed water

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

Optional purple handle provides additional indication of reclaimed water use.

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Includes the required wall plate and a purple wall flange to let users know reclaimed water is in use.

All organic rubber has been replaced with synthetic compounds

Interior components are purple to let maintenance personnel know the flushometer is designed for reclaimed water

Critical components, including cover, valve body, control stop and sweat solder kit, are made of semi-red brass

Optional purple handle provides additional indication of reclaimed water use.

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Flush volumes start as low as 1.28 gpf/4.8 Lpf

Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents toilet from exceeding intended flush volume

Flush accuracy is controlled by CID™ technology, also enhancing water efficiency

Integrity of the product is maintained with the vandal-resistant stop cap

Durability is facilitated with high copper, low zinc brass castings for dezincification resistance

Adjustable tailpiece

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass

Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass

Valve shall be in compliance to the applicable sections of ASSE 1037

Complete urinal system including ECOS HW flushometer Designed to maximize performance

Thorough washdown flushing action

Durable, hygienic vitreous china construction

Vandal resistant stainless steel strainer included

IAPMO certified to meet or exceed ASME A112.19.2 standards

Water Sense listed by EPA that qualifies for most rebate programs

Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly
