Product Code
SU-7009
Product Type
Date Updated
1760486400
Product Category
Url Slug
su-7009
Primary Description
Small Washdown Urinal
Product Features
Features List
Designed to maximize and complement Sloan flushometers
Small size and clean lines fits a large variety of applications and restroom looks
Thorough washdown flushing action
Vandal resistant stainless steel strainer included
IAPMO certified to meet or exceed ASME A112.19.2 standards
Water Sense listed by EPA that qualifies for most rebate programs
Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly
Downloads
Downloads Product Group
Title
BIM Model
Files Dowloads
Title
Brochure
Files Dowloads
Title
Installation Instructions
Files Dowloads
Title
Repair & Maintenance Guide
Files Dowloads
Title
Transparency Reports
Files Dowloads
General Spec Sheet
Series Description
Vitreous China Washdown Urinal
Measure Length
14.75in
Measure Length (mm)
375.00mm
Measure Width
14.19in
Measure Width (mm)
360.00mm
Measure Height
23.50in
Measure Height (mm)
597.00mm
Product Line
Urinal Flush Volume gpf
0.13gpf
Urinal Fixture Connection
Top
Urinal Flush Method
Washdown
Urinal Type
Small
Urinal Product Line
Spec Sheet Description
Standard
