Product Code
WES-1000
Product Type
Date Updated
1760486400
Product Category
Url Slug
wes-1000
Primary Description
Standard Waterfree Urinal
Product Features
Features List
Uses no water for maximum LEED credits and minimal water and sewage costs
Conserves up to 40,000 gallons of water each year
Touch-free operation promotes hygiene and eliminates cross contamination
Patented, sealed locking cartridge engineered to last for an average of 7,000 uses
Five new and improved features minimizes odors and mess
cUPC certified to meet or exceed ASME 112.19.19 standards
Meets ADA guidelines and ANSI A117.1 requirements when installed accordingly
Red List Free
Downloads
Downloads Product Group
Title
BIM Model
Files Dowloads
Title
Brochure
Files Dowloads
Title
Installation Instructions
Title
Repair & Maintenance Guide
General Spec Sheet
Series Description
Vitreous China Waterfree Urinal
Measure Length
14.38in
Measure Length (mm)
365.00mm
Measure Width
19.63in
Measure Width (mm)
498.00mm
Measure Height
26.75in
Measure Height (mm)
679.00mm
Product Line
Urinal Flush Method
Waterfree
Urinal Type
Standard
Urinal Product Line
Spec Sheet Description
Standard
